SS316 Sintered 10 Micron Filter Element For Access Port High Pressure Filter

Stainless Steel 316 Sintered 10 Micron Replacement Filter Element for access port High Pressure Filter

The stainless steel filter element is made of stainless steel powder by pressing through the mold, sintering at high temperature and forming integrally. Stainless steel filter element features stable shape, and its anti impact and alternating load capacity is superior to other metal filter materials; Good permeability and stable separation effect; Excellent strength, suitable for high temperature, high pressure and strong corrosive environment; Especially suitable for high temperature gas filtration. Stainless steel wire mesh is made of multi-layer metal woven wire mesh by lamination pressing, vacuum sintering and other processes. The mesh of each layer of wire mesh is interlaced to form a uniform and ideal filtering structure, which overcomes the shortcomings of low strength, poor rigidity and unstable mesh shape of ordinary metal wire mesh, and has less flexibility to control the cleanliness of equipment, so that the pore size, permeability and strength characteristics of materials can be reasonably matched and designed, making it have excellent and accurate filtering accuracy, filtering impedance, mechanical strength, wear resistance The heat resistance and processability make the filtering effect easy to control, and thus it is widely used as an ideal filter element.

Because its filtering mechanism is surface filtering and the mesh channels are smooth, it has excellent backwashing and regeneration performance (countercurrent water, filtrate, ultrasonic, melting, baking, etc. can be used), and can be used repeatedly for a long time, especially suitable for continuous and automatic operation process. The main difference between sintered filter element and other filter elements is that a large number of high-precision welding processes are used.

 The sintered mesh is welded on the end covers at both ends through stainless steel welding wire. The sintered mesh cannot be burnt during welding to prevent local burning, which will cause the filter element to fail to filter. Therefore, the welding environment must be protected by argon during welding. In the welding process, all welding tooling and special welding equipment must be provided, and the welding technical requirements for workers are relatively strict. In case of air leakage in the pressure range of bubble test after welding, all filter elements shall be scrapped.

Technical Index of Stainless Steel Sintered Fiber Web


Company Profile


Kainuosen Environmental Technoiogy (Langfang) Co.,Ltd. Founded in 1995,The production base is loed in the North China Industrial Zone.We are loed in the economic coverage areas of Beijing, Tianjin, and Hebei, close to sea ports such as Tianjin Port, Qingdao Port, Weihai Port, and Qinhuangdao Port.It is only 15 kilometers away from Beijing Daxing International Airport, with superior geographical loion and convenient transportation.

Our company is a comprehensive high-tech enterprise integrating R&D, design, production, maintenance, sales and after-sales service. It is based in China and serves the world.

Our company produces all kinds of filter elements, cartridges and filters used in machinery, automobiles, ships, steel mills, power plants, mines, pumps, compressors, air compressors, dust treatment, water treatment, etc.

Products include air filters, oil filters, fuel filters, hydraulic oil filters, oil and gas separation filters, oil-water separation filters, coalescing separation filters, industrial air filters, dust filters, stainless steel filters, vacuum pump filters , Oil filter, concrete mixing plant large pulse dust filter, dust filter cartridge and other types, thousands of different specifiions series of filters, instead of brand filters, and can be customized according to customer requirements, support OME processing and production.

Focus on creating a filter brand and commit to the future of clean industry. We have a large number of technical elites, and we represent quality, focus and integrity. We are a supplier of industrial filtration solutions. We are Kainuoson.




Our Factory





Packing & Delivery






FAQ

1. Who are we?
We are loed in Hebei, China. We have 20 years of production experience. Since 2015, we have sold to the domestic market (40.00%), Africa (20.00%), North America (10.00%), Eastern Europe (10.00%), South America (8.00%) , Southeast Asia (7.00%), East Asia (3.00%), Western Europe (2.00%). There are about 11-50 people in our office.

2. How do we guarantee the quality?
It is always a pre-production sample before mass production;
Always perform a final inspection before shipment;

3. What can you buy from us?
Filter element, hydraulic filter, dust removal equipment, industrial air filter, dust filter cartridge, natural gas filter, oil-water separation filter, oil-gas separation filter, oil filter, fuel filter, etc.

4. Why buy from us instead of other suppliers?
Our company produces various filter elements, filter elements, filters for machinery, ships, steel plants, power plants, compressors, air compressors, dust treatment, etc., and can be customized according to customer requirements. Based in China, service

5. What services can we provide?
We provide after-sales service and technical support, we can customize various types of filters for you, or OME processing.
